Why Graphics Cards Matter And How To Pick The Right One For Your Needs

Why Graphics Cards Matter And How To Pick The Right One For Your Needs

GPUs were originally designed to modify data in the computer’s frame buffer and display it as pixels on paper, a role that CPUs were not designed to do. It needed processors that could perform a large number of reasonably simple calculations quickly and simultaneously.
The introduction of polygonal 3D graphics resulted in programmable pixel and vertex shaders, which in turn resulted in the GPGPU – or general-purpose graphics processing unit – which first appeared in the early 2000s. Essentially, it ensures that the processors in a GPU may be called upon to relieve the CPU of any of the heavy lifting. They are suitable for routine activities such as raytracing a 3D render or running complex simulations.

Mobile energy

At the most basic stage, there are low-cost PC notebooks with an embedded GPU – one that is directly installed into the CPU. These are often underpowered in terms of efficiency, but they are energy sensitive, allowing you to operate for hours without exhausting the battery.
An optimised GPU would suffice for watching videos, browsing the internet, and playing casual games, but it can struggle with innovative ventures. If you need more resources, search for laptops with a discrete GPU: both Nvidia and AMD manufacture mobile versions of their desktop cards, which have enough power for most artistic activities, with the exception of 3D animation and rendering.
However, more costly (and bulkier) laptops can be outfitted with high-end GPUs such as Nvidia’s GeForce RTX 2080. You’ll pay a premium for this configuration, but if you need value on the go, the laptop form factor is no longer an issue. Only remember to bring a power adapter.

Why Graphics Cards Matter And How To Pick The Right One For Your Needs
Why Graphics Cards Matter And How To Pick The Right One For Your Needs

Configuration of the desktop

When it comes to laptop configurations, you have a lot of options for GPUs. Not only because there are so many versions and choices, but also because there is a thriving second-hand industry. Since high-end gamers update often, you will also find last-gen versions for less money online. Though last year’s GPU might not be up to the task of playing the new Modern Warfare in 4K, it may be perfect for your image, film, or animation needs. For eg, Nvidia’s GeForce GTX 1080 Ti (released in 2017) is a beast of a card that can be had for less than £400 if you shop around.

If it is not a good thing to cut corners on your schedule, you still do not have to purchase the most costly GPU you can purchase. It’s tempting to splurge on a flashy new card with loads of VRAM – but unless you’re dealing with massive CAD files or doing 3D modelling, something more than 8GB is possibly overkill. Similarly, why pay a premium for one of Nvidia’s RTX GPUs if none of the applications support raytracing?

The GeForce GTX 1080 Ti from Nvidia is a beast of a graphics card.

One critical concern is whether the programmes are GPU-accelerated. If your apps use OpenCL, they can run for both Nvidia and AMD cards, but if they use CUDA (Compute Unified Device Architecture), you will require an Nvidia card.

Additional GPUs have more power in some workflows, but in most cases – outside of intense video work or 3D rendering – a single strong GPU is always sufficient; you may add more, but you still won’t see enough gain to warrant the expense. You would need to do some research to find the best combination of power and price for the activities you do. Consider how many displays you need and the resolution you operate in; a low-cost card can fail to drive two 4K monitors whilst still handling complicated video or effects work.

Outside of intense video work or 3D modelling, a single strong GPU is always sufficient in a standard system.

Nvidia already occupies the high end with its RTX 2080 and 2070 cards (and their popular Ti variants), but AMD responded this summer with the Radeon VII, the company’s first 7nm GPU with a healthy 16GB of VRAM. In most cases, the card is competitive with the GTX 2080, but it is a little power-hungry.

3D modelling

We separated 3D rendering since it is a very special event. In recent years, there has been a significant trend away from CPU rendering and toward GPU rendering. There are numerous dedicated GPU-based applications available, such as Octane, Redshift, and Cycles, and conventional CPU-bound renderers such as Arnold, V-Ray, and Keyshot have recently introduced GPU acceleration. They all currently use Nvidia’s CUDA libraries to conduct real-time ray tracing and, of course, an Nvidia GPU is needed (and as many as you can slot into your PC case). The newest RTX cards display significant efficiency improvements, such as being up to three times quicker in Octane.

Though Nvidia has dominated this business over the past five years, AMD is not out of the running. It has its own app, Pro Render, that runs on both Nvidia and AMD GPUs and uses OpenCL. In addition, the Octane and Redshift developers have all dedicated to porting their renderers to Apple’s Metal API, which is only enabled by AMD cards. AMD is still focusing on its own hardware ray tracing implementation, with its next-generation rDNA GPUs expected to be unveiled at CES in January 2021.

We can’t even fight about heading Nvidia to use CUDA-accelerated renderers right now, but the war for GPU rendering is far from over.

Cards for workstations

Nvidia’s Quadro workstation-class GPUs are named as such, whereas AMD’s are branded as Radeon Pro. At first glance, the specifications of the cards will seem identical or sometimes worse than those of their consumer-level counterparts, but they are engineered for accuracy and robustness rather than outright speed, like a gaming GPU is.

Engineers, programmers, 3D animators, and anybody else who works in computer graphics would benefit from workstation cards. The drivers are qualified for use with unique applications, and they are often designed to manage multi-million polygon scenes, so they frequently provide significant volumes of error-correcting (ECC) VRAM, usually a minimum of 8GB and as high as 48GB.
